Pipeline surveys are land surveys that are conducted for the purpose of placing or maintaining pipelines.
They serve multiple purposes, including determining the most efficient route for new pipelines and checking for damage in existing pipelines.
Surveyors collect data on the elevation of the surface-level terrain as well as the depth of the pipeline.
With the help of advanced technology, accurate survey data can be obtained without excavation, enabling the detection of cracks or corrosion for pipeline integrity.
The main goal of pipeline surveys is to ensure that pipelines do not cause damage or interact with nearby utilities, groundwater, or other pipelines.
Proper research is conducted beforehand to minimize risks and avoid delays.
Land surveys are used to verify the proposed route of a new pipeline, as even slight changes in direction or location can impact economic feasibility.
Easements must be secured from private and public property owners for access to land.
Surveyors pay close attention to natural or manmade features that could interfere with the pipeline, such as bodies of water or farmland.
Preliminary surveys provide an overview of the terrain and identify notable features.
Routing surveys are then conducted to finalize the pipeline route, taking into account elevation gradients and possible bends or turns.
The construction staking process ensures that pipeline information is clearly marked above ground before the pipeline is placed.
As-built surveys are conducted during pipeline placement to comply with building codes or satisfy lenders.
McClure offers professional pipeline surveying services for all stages of the process and utilizes advanced technology to accurately survey existing pipelines without excavation.
They can also assist with alignment design and plan preparation for optimal pipeline routing.
By securing easements from property owners and conducting thorough surveys, risks are mitigated, and disasters like cross-boring can be prevented.
Key Points:
- Pipeline surveys are conducted to place or maintain pipelines and serve multiple purposes.
- Surveyors collect data on the elevation and depth of the pipeline using advanced technology.
- The main goal of pipeline surveys is to prevent damage to nearby utilities, groundwater, or other pipelines.
- Proper research and easements from property owners are important for minimizing risks and avoiding delays.
- Preliminary and routing surveys are conducted to finalize the pipeline route, taking into account terrain features.
- McClure offers professional pipeline surveying services and can assist with alignment design and plan preparation.
